The PA91 is the perfect pump for in-ground pools up to 15,000 gallons. It is also the ideal upgrade for above-ground pools. Equipped with quick-disconnect unions. Available with 115V or dual voltage 115/230V motors.

FEATURES:

• Product Information 115V
• Product Information 115/230V
• PA91 Manual

• • This high performance, medium head pump comes complete with an industry standard 5/8″” mechanical seal for convenient replacement
  • Pump parts are made of 100% recyclable plastic. Non-corrosive, chemical/UV resistant, and can withstand temperatures of up to 150° F (65.5° C)
  • Suction and Discharge ports are equipped with quick disconnect unions. Provided with a standard 1.5″ ” slip and 1.5″”/ 1.25”” hose adaptor connections. Optional 1.5” NPT connections available.
  • For pool users’ safety, the impeller has a dielectric shaft sleeve that provides absolute separation between pool water and electric parts.
  • The Model PA91 comes complete with a full 24 month warranty.
  • Optional 4” high base is available on 115V model.
  • Specially constructed clear lid with ring lock design is easy to open. Large strainer basket is always locked in place.
  • Pump is equipped with durable, special 48″ frame thru-bolt mount energy efficient PSC motor with stainless steel shaft.
  • Pump has a standard 3 ft. 3/12″ AWG cord set pre-mounted. A variety of other cord sets are available (115V model).

• The Model PA91R is equipped with a special 48″ frame thru-bolt mount energy efficient PSC motor with stainless steel shaft (115/230V model).
• The Model PA91R is listed on the California Energy Commission’s Appliance Efficiency Database for residential pool pumps and complies with the APSP-15 standard (115/230V model).
• Every pump is performance tested before leaving the factory.

Important Notice: Pumps offered for sale, or installed in a residential pool for filtration use in California must be listed on the California Energy Commission website. (Title 20, sections 1601-1609) Please consult the CEC list, search company, Speck Pumps.
